Horizontal Machining Center 950A Precision Processing For Box Parts

Horizontal Machining Center Precision Processing For Box Parts HMC-950A

The General Horizontal Machining Center integrates advanced international design concepts, featuring a ball guide T-bed structure and a forward hanging box layout. Its three-axis, high-rigidity roller guide system ensures the perfect balance of precision and efficiency, making it ideal for rough and finishing operations on various box parts.

Machine Type	Unit	HT-63	TH814
Table size	mm	1360×700/630×700	2000×900
Table No.		1	1
Table division	°	1°×360	1°×360
Table transmission ratio		240	240
Max. table loading capacity	kg	950	1600
Table surface type	mm	T-slot	T-slot
Max. workpiece turning dia.	mm	1000	1800
Table left&right travel(X axis)	mm	1200	1800
Spindle box up&down travel(Y axis)	mm	900	1400
Table front&back travel(Z axis)	mm	700	900
Distance from spindle center to table surface	mm	90-810(75-975)	20-1420
Dsitance from spindle nose to table center	mm	165-865	200-1100
Spindle bore taper		BT50-190	BT50-190
Spindle speed	r/min	20-6000	20-6000
Tool type		MAS 403 BT50	MAS 403 BT50
Rivet type		MAS 403 P50T-1	MAS 403 P50T-1

1. Charactrisitic

General horizontal machining center, integrated with the international advanced design concept, the use of ball guide structure Tbed, forward hanging box layout, three axis high rigidity roller guide to achieve the perfect integration of high precision and high efficiency processing for various box parts rough finishing.

2. Standard Configuration


Taiwan arm type ATC: 24 T arm type tool magazine, repeated tool change time, increase production efficiency.	Taiwan precision roller guide rail: Roller line rail, high precision, smooth movement, suitable for high-speed mobile processing.	Imported lubricating oilpump: oil pump standard with HERG/BAOTN: pneumatic components Air TAC, to ensure oil lubrication and pneumatic pressure	Controller system: Optional: Japan Fanuc/Misubishi, Simens, Taiwan Syntec, Beijing KND, Guangzhou GSK
